I recently tried to move all my DNS records for web resources deployed over the internet to the unified network of cloudflare as they are just great at what they do with all the services and network protection.

I will walk through the setup cloudflare to use as nameserver, DNS record management, and SSL/TLS setup. There is plenty more at cloudflare like rate limiting as well.

Let’s get this out of the way first Domain Name System (DNS) is a way to translate domain names like blog.king-11.dev to its IP Address.

host blog.king-11.dev
blog.king-11.dev has address 172.67.164.94
blog.king-11.dev has address 104.21.66.209
blog.king-11.dev has IPv6 address 2606:4700:3033::6815:42d1
blog.king-11.dev has IPv6 address 2606:4700:3032::ac43:a45e

The resources I moved from multiple different providers included:

  • Custom Domain
  • Static Github Pages Website
  • Dynamic NextJS Website
  • Home Server Network Tunnel

Let’s dive into how my late night network shenanigans went.

Custom Domain

I had a great time just using github.io, vercel.app and netlify.app. These service providers are amazing and offer you a lot for free. But there were primarily two reason for my switch:

  • I wanted to setup a cloudflare tunnel for my jellyfin server at flat so that I can binge watch my series and movies from anywhere in the world
  • Having everything under a single umbrella helps in developing the brand as people remember it easily so why not?

Purchasing Domain

So after asking people what top level domain (TLD) should I buy and thinking a little about getting free ones. I unloaded my pockets and got myself king-11.dev from Namecheap.

The only issue was they didn’t provide INR payment options just like cloudflare so I had to use my OneCard as that provides a good forex rate of 1% only.

namecheap purchase

I could have bought the domain from cloudflare too they are the most transparent in terms of domain registration as they only ask for the registration charges and nothing else. But their paypal integration wasn’t working for me and namecheap was cheaper so went with it.

Nameserver

Nameserver is the server which contain DNS records for your domain. Think of it like a phonebook which contains your addresses, there can be many phonebooks but only one some will contain your details.

graph LR
  B[Browser] -->|domain| N[Nameserver] --> |ip address| B

To manage my custom domain on cloudflare I had to update my nameservers on namecheap and point them to the ones that cloudflare provided me.

To verify that nameserver is set properly we can use dig command

dig king-11.dev NS +short
mark.ns.cloudflare.com.
ollie.ns.cloudflare.com.

Now the domain is in hands of cloudflare it can now easily create new DNS records for my domain name.

Security Settings

We can do additional setup to ensure that the content is transferred securely between all involved entities. To do this will enable full SSL (Secure Socket Layer)/TLS (Transport Layer Security). Under websites -> king-11.dev -> SSL/TLS, we would set my encryption mode to Full.

graph LR
	B(Browser) -->|🔒| C(Cloudflare)
	C -->|🔒| O(Origin Server)

Furthermore, I can upgrade all the HTTP connection to HTTPS which returns content to user over a secure transport channel.

  1. Under the SSL/TLS section, there is option of Edge Certificates
  2. Under Edge Certificates, we can enable “Always Use HTTPS”
graph TD
	B(Browser) -->|1. HTTP Connection| C(Cloudflare)
	C -->|2. 307 Internal Redirect| B
	B -->|3. Connection Redirect| B
	B -->|4. HTTPS Connection| C

Github Pages

I have been using github pages to deploy my static sites which included my blog repository. It uses a github action to build and then publish my hugo based site onto github pages.

The change I needed to make here was

  1. Add the custom domain in Settings -> Pages section.
  2. Create DNS entry in cloudflare to point blog.king-11.dev towards a github server.

But I don’t know the server neither does cloudflare’s nameserver and given I am no more using king-11.github.io/blog that entry would just redirect to my custom domain. So who will find me the ip address for my site?

CNAME Entry

Given github is the only one aware about the IP Address of my server, cloudflare needs to add a mapping such that dns resolution for my subdomain is offloaded to github.

This is exactly what CNAME records provide a DNS level redirection, they map one domain to another domain where both can be handled by different nameservers.

graph LR
	B[(Browser)] -->|blog.king-11.dev| C[(Cloudflare)]
	C -->|blog.king-11.dev| G[(Github)]

So in the above case when users asks cloudflare for blog site it redirects user to github which given the custom domain configuration settings know which server this domain points to and can provide user the result i.e. an A Name Record (domain -> IP).

To see this in line action we can use the command

dig blog.king-11.dev +trace

Mixed Content Bug

After all this process it started to happen that the cover of my blogs wasn’t visible anymore. Checking the console of browser the issue was that

Mixed Content: The page at ‘https://blog.king-11.dev/posts/memory-management/' was loaded over HTTPS, but requested an insecure image ‘http://blog.king-11.dev/posts/memory-management/cover_hu3f9b19c18b96efe8ccfa749888a579de_415626_720x0_resize_q75_h2_box_2.webp'. This request has been blocked; the content must be served over HTTPS.

So browsers don’t allow accessing any HTTP (insecure) resource from an HTTPS (secure) page. But why was it using http?

I tried setting cloudflare to redirect http to https itself but browser was already blocking any http connection before even going out of the browser. I checked the generated html of my blog page to find the image component as

<img loading="lazy" srcset="http://blog.king-11.dev/posts/memory-management/cover_hu3f9b19c18b96efe8ccfa749888a579de_415626_360x0_resize_q75_h2_box_2.webp 360w ,http://blog.king-11.dev/posts/memory-management/cover_hu3f9b19c18b96efe8ccfa749888a579de_415626_480x0_resize_q75_h2_box_2.webp 480w ,http://blog.king-11.dev/posts/memory-management/cover_hu3f9b19c18b96efe8ccfa749888a579de_415626_720x0_resize_q75_h2_box_2.webp 720w ,http://blog.king-11.dev/posts/memory-management/cover_hu3f9b19c18b96efe8ccfa749888a579de_415626_1080x0_resize_q75_h2_box_2.webp 1080w ,http://blog.king-11.dev/posts/memory-management/cover.webp 1080w" sizes="(min-width: 768px) 720px, 100vw" src="https://blog.king-11.dev/posts/memory-management/cover.webp" alt="" width="1080" height="1080">

So, the src tag is correct but image is loaded using srcset (due to precedence) whose urls are prefixed with http. Now I updated my baseURL in hugo config file but still nothing was happening generated html was still using http only.

So I checked further github without information that SSL/TLS is enabled on my system was passing http://blog.king-11.dev to my github action which wasn’t using baseURL set in config file. Finally, it made sense leading to a final commit with the following diff

	 run: |
	   hugo \
		 --gc \
-        --minify \
-        --baseURL "${{ steps.pages.outputs.base_url }}/"
+        --minify
   - name: Upload artifact

Vercel Redirection

After going through github vercel setup was a breeze. Again given vercel deploys my site it has the A Name Record for it. So on cloudflare I just need to add a CNAME record pointing my root to vercel’s cname domain and rest vercel handles on its own.

Two key things useful for vercel is:

  • Set SSL/TLS encryption to Full mode initially it is flexible, which can lead to ERR_TOO_MANY_REDIRECTS
  • Enabling Always Use HTTPS allows ACME protocol used to validate the domain ownership to bypass restrictions and use http.

What came in handy here is vercel has a great documentation for bugs, troubleshooting and setup 🎉.

Cloudflare Tunnel

So this all started from cloudflare tunnels. I have added details in my post The Hacker Way of Living about how I use self hosting to keep a personal library of movies and series, downloaded using torrent and hosted on my raspberry pi 4 using jellyfin media server.

To access it umbrel provides tor based access which is very slow so I needed a faster solution. There was Tailscale VPN which wasn’t working so the other option was cloudflare tunnel.

graph LR
	B((Browser)) -->|jellyfin.king-11.dev| C[(Cloudflare)]
	O[(Origin Server)] --- D[cloudflared]
	D --> C
	M((👨‍💻)) --x D

So while there is a connection between cloudflare and cloudflared (d is for daemon process) on my raspberry pi, no other user can access it. I can then use cloudflare to serve it on a custom domain which I purchased.

We can go on our dashboard, Zero Trust -> Networks -> Tunnels to create a new tunnel. Now to expose it or even multiple other endpoints we need to add our public ip and what it internally maps to on the origin server.

Conclusion

So the idea was for me to easily access my jellyfin from anywhere in the world while my raspberry pi 4 easily sits at my flat. Sadly, my flatmate unplugged it and forgot to plug it back. unplug

Screams!, first of all you never unplug a server without properly shutting it down it will lead to data corruption. And secondly the server always stays plugged in. I need to set some new flat rules and setup warnings signs. Alexa play “new rules” because I don’t have tickets to go and see dua lipa 😭.

That was all for this time, it was quite some learning about networks that my computer science course didn’t even care to touch. I hope when you try to setup your own custom domain or self host things this blog would come handy. Thanks for reading see you next time after my next trip :P.
