Efficient Gossip in Distributed Systems

I have been interested in distributed systems for quite some time. Recently, I started solving the Fly.io Distributed Systems Challenge after putting it off halfway through. Amongst the challenges the Broadcast challenge revolved around getting a better understanding of how to make fault resilient, consistent and efficient distributed system for broadcasting messages.

Through this blog I will try to share my learnings and thought process solving the challenge which includes identifying the use of gossip, reducing message passing latency and finally doing efficient network communications.

Broadcast System

In this broadcast system we have n server nodes and some clients which send requests to our servers.

The possible type of messages that system supports as Remote Procedure Calls (RPC) are:

• Read: In response to this the server should return all values it has seen till now.

{
  "type": "read"
}

• Broadcast: The value sent in broadcast should be stored locally by the server.

{
  "type": "broadcast",
  "message": 1000
}

• Topology: This message informs the node of who its neighboring nodes are.

{
  "type": "topology",
  "topology": {
    "n1": ["n2", "n3"],
    "n2": ["n1"],
    "n3": ["n1"]
  }
}

We run our nodes on maelstrom using the below command

./maelstrom test -w broadcast --bin ~/go/bin/maelstrom-broadcast --node-count 5 --time-limit 20 --rate 10

Fault Tolerance

maelstrom supports introducing nemesis. For this challenge it would be network partition where nodes won’t be able to communicate for a short period of time.

./maelstrom test -w broadcast --bin ~/go/bin/maelstrom-broadcast --node-count 5 --time-limit 20 --rate 10 --nemesis partition

So we have to make sure that values should propagate to all other nodes by the end of the test. We need to worry about values that arrived during network partitions as our system failed to propagate them in face of nemesis.

To make our system resilient to network partitions, we use a technique called gossip. In gossip protocols, nodes periodically share information with other nodes to ensure everyone stays up-to-date. The nodes which sees a new value then can further propagate it to their neigbhours.

We introduce a new message of type Gossip, as below because the Broadcast message would require multiple messages to send all the values.

{
  "type": "gossip",
  "messages": [11, 08, 2002]
}

We will run a separate thread that will be invoked at GOSSIP_FREQUENCY and select GOSSIP_NODE_COUNT number of nodes randomly and send all its messages to them. I kept the values at 2s and 2 nodes respectively.

Reducing Read Latency

The requirements for Efficient Gossip Part I are as below:

• Messages-per-operation is below 30, shows the number of messages exchanged per logical operation.
• Median latency is below 400ms
• Maximum latency is below 600ms

Along with this there are new configuration as well:

• The node count has been increased to 25
• Messages have a latency of 100ms to simulate a slow or busy network.

The most important information that was present in the challenge description was

The neighbors Maelstrom suggests are, by default, arranged in a two-dimensional grid. This means that messages are often duplicated en route to other nodes, and latencies are on the order of 2 * sqrt(n) network delays.

The challenge further encouraged us to do what was necessary

Feel free to ignore the topology you’re given by Maelstrom and use your own; it’s only a suggestion.

So based on the understanding that we need to manipulate our topology I first tried a circular one.

I tried this because I was familiar with chain replication distributed system. But this didn’t perform as expected it was resilient to faults but pretty slow. From complexity analysis we can see it can take as long as O(N) for it to work.

So we need something better than linear and square root (grid), the thing that programmers love is logarithmic. The data structure which can provide us this is a balanced tree. So I planned to make use of binary heap for this where neighbours are defined as below

n := len(s.n.NodeIDs())
n1 := (2 * i + 1) % n
n2 := (2 * i + 2) % n

Just to demonstrate how this looks in a system with 6 nodes

In some cases, our formula results in node itself. This worked fine in my test runs, which implies we can have a little discrepancy in large distributed system.

I also increased the gossip frequency and gossip nodes to 5s and 5 respectively for a larger system to keep message count low.

Efficient Network Communication

With the same configuration as above the requirements for Efficient Gossip Part II are:

• Messages-per-operation is below 20
• Median latency is below 1 second
• Maximum latency is below 2 seconds

The thing here is we want to reduce our number of messages further at the cost of an acceptable latency value. This might be because the cost of network isn’t free for most cloud providers.

To achieve this message count we would have to act lazily and not in an eager manner. Earlier we were sending new messages received to our neighbours instantly through a message of type Broadcast.

The change we introduce is Message Batching. Instead of sending each message to neighbours separately we keep a batch of unsent messages. At NEIGHBOURS_FREQUENCY frequency we will send this batch of messages to our neigbhours as Gossip.

I was able to achieve better than expected latency under 1s with message-per-operation of 16. The frequency I used to send batched messages was 50ms.

Programmatic Optimizations

Even though the system is most affected by the above choices there were micro improvements that I did to ensure even better results. They were as follows:

• Using a lock free map to reduce contention due to mutex locks. For this Go offers sync.Map implementation in standard library.
• Making use of channels and goroutines to perform blocking I/O so that multiple operations can work concurrently.

For further reading on implementation details I asked o3 to write me a README based on my code.

Conclusion

Working through the Fly.io Distributed Systems Challenge taught me that building efficient gossip protocols is all about making smart tradeoffs. The biggest improvements came from making architectural changes rather than code optimizations, which were:

• Introducing Gossip message to keep the message exchanged count low
• Using messsage batching for efficient network communication
• Switching from grid to binary heap like topology reducing the system latency

Whether you’re building a chat system, a database, or any distributed application, gossip protocols offer a simple way to achieve consistency without complex coordination. The key is finding the right balance between message overhead, latency, and fault tolerance for your specific use case.

The complete implementation is available on GitHub if you want to dive deeper into the code. Thanks for reading the blog, I will further cover up a few more parts about the challege so stay tuned and as always you can find me at @1108King
