Mastering Jackson Annotations • Backpacking Dream

I have been encountering more and more aha moments while working with Jackson Annotations primarily because we usually don’t write tests for stuff like serialisation and deserialisation of JSON because the code is way too trivial to have tests for and who even does that, right?

But these kinds of issues can break production ~~already did once~~. So here is everything I have figured out until now around serialisation of records/classes/empty beans, deserialisation along with property naming and the interesting case of interfaces with concrete types.

Serialisation Annotations

A Java class is serialisable for Jackson if it belongs to any of the below scenarios.

POJO Class

If it’s a normal Java class then it needs to have public fields, as only fields which are public will be visible in the serialised format of the class.

public class DatabricksDashboard {
  public String dashboardId;
  public String deploymentName;
}

Record Class

It is a record class that provides out of the box serialisation and de-serialisation; so no annotation is required.

public record DatabricksDashboard(
  String dashboardId,
  String deploymentName) {}

Renaming Fields

We can rename field names present in serialised JSON using JsonProperty("<NEW_NAME">) annotation.

To create the JSON object that looks like

{
  "dashId": "1234",
  "dpName": "cache-key"
}

We can define our records or even class by giving the JsonProperty annotation to field declarations

public record DatabricksDashboard(
  @JsonProperty("dashId") String dashboardId,
  @JsonProperty("dpName") String deploymentName) {}

Empty Beans

Jackson’s ObjectMapper by default fails to serialise a class with no public fields or as Jackson likes to call it, an empty bean (legacy of Spring Boot). There are two workarounds for it:

Allowing classes with empty fields for ObjectMapper

private static final ObjectMapper objectMapper =
  new ObjectMapper()
    .configure(SerializationFeature.FAIL_ON_EMPTY_BEANS, false)

Adding a JsonSerialize annotation on individual class

@JsonSerialize
public class EmptyClass {}

Either of the above is fine to use; it depends mostly on whether there is only one ObjectMapper instance you need to change or multiple.

Deserialising Annotations

Deserialisation of JSON into a Java class happens through its constructor. Jackson maps the fields present in the JSON object to the keys present in class constructor.

Let’s try to deserialise a JSON object that looks as below

{
  "dashboard_id": "1234",
  "deployment_name": "captcha-check"
}

We need to add the annotation of JsonCreator to the constructor function responsible for generating our class from the JSON object input.

For each field in our JSON input, we have to annotate the respective constructor argument with JsonProperty.

public class DatabricksDashboard {
  public final String dashboardId;
  public final String deploymentName;

  @JsonCreator
  public DatabricksDashboard(
    @JsonProperty("dashboard_id") String dashboardId,
    @JsonProperty("deployment_name") String deploymentName
  )
  {
    this.dashboardId = dashboardId;
    this.deploymentName = deploymentName;
  }
}

Useful Annotations

Jackson has developed some pretty useful annotations for frequently encountered cases some of them that I use very often are:

@JsonNaming(PropertyNamingStrategies.SnakeCaseStrategy.class)
@JsonIgnoreProperties(ignoreUnknown = true)

JsonNaming

Given that in Java we prefer using camel case, our property declaration is done the same. Though it’s possible that the JSON we are trying to deserialise uses a different case.

The way to deal with it is using renaming fields as we have already seen above but it gets too verbose in which case we can just make use of JsonNaming annotation.

@JsonNaming(JsonPropertyNamingStrategies.SnakeCase.class)
public record DatabricksDashboard(
  String dashboardId,
  String deploymentName) {}

Now the above class can read JSON without any additional annotation that looks as below

{
  "dashboard_id": "1234",
  "deployment_name": "cache-key"
}

Some of the useful naming strategies are:

Snake Case
Pascal Case
Kebab Case
Camel Case Apart from these there is a whole set of combinations around upper and lower case to cater to other requirements.

JsonIgnoreProperties

The JSON payload we are trying to deserialise can have multiple properties that we don’t really care about in our application logic. If we ignore those properties in our class, then Jackson will raise an error during deserialisation.

There are three ways to deal with this:

Declare the field in JsonCreator constructor but don’t assign it to any of the fields

public record DatabricksDashboard(
  @JsonProperty("dashboard_id") String dashboardId,
  @JsonProperty("deployment_name") String _deploymentName) {}

Update your object mapper to ignore unknown properties

new ObjectMapper().configure(Feature.IGNORE_UNKNOWN, true);

Add the JsonIgnoreProperties annotation to your class

@JsonIgnoreProperties(ignoreUnknown = true)
public record DatabricksDashboard(
  @JsonProperty("dashboard_id") String dashboardId) {}

Working with Interfaces

It’s easy to work with concrete types (i.e. classes/records), because there is a 1:1 mapping between JSON payload and our class; but when it comes to interfaces there is n:n mapping that Jackson has to figure out.

To provide additional information to Jackson, we can use the JsonTypeInfo annotation. It will help Jackson figure out the right class while trying to deserialise the JSON into a concrete class object.

Let’s assume we have a sealed interface for some dashboard information

public sealed interface DashboardInfo
    permits DatabricksDashboard, SigmaDashboard {
  String id();
  String content();
}

Our interface is implemented by two record classes, each of them has some additional fields, apart from the ones that the interface asks for

public record DatabricksDashboard(String id, String content, String deploymentName) implements DashboardInfo {}

public record SigmaDashboard(String id, String content, String deploymentName, String creator) implements DashboardInfo {}

Now assume we have a serialised List<DashboardInfo>. How will Jackson know which class to deserialise each of the list objects into, while recreating the list?

[
  {
    "id": "databricks-1",
    "content": "hello databricks",
    "deploymentName": "dbc-1234"
  },
  {
    "id": "sigma-1",
    "content": "for the ceo",
    "creator": "chief of staff"
  }
]

To add type information, we can add a new property in our JSON object which is distinct for each of our classes and helps Jackson figure out the right one. We do it using the JsonTypeInfo annotation.

@JsonTypeInfo(
    use = Id.NAME,
    include = JsonTypeInfo.As.PROPERTY,
    property = "_type")

Now we also need to declare what the value is for each of our subtypes on our interface

@JsonSubTypes({
  @Type(value = DatabricksDashboard.class, name = "databricks"),
  @Type(value = SigmaDashboard.class, name = "sigma"),
})

Our serialised List<DashboardInfo> will look as below now

[
  {
    "id": "databricks-1",
    "content": "hello databricks",
    "deploymentName": "dbc-1234",
    "_type": "databricks"
  },
  {
    "id": "sigma-1",
    "content": "for the ceo",
    "creator": "chief of staff",
    "_type": "sigma"
  }
]

We chose to add these values manually but we can also go with something like use = Id.CLASS which just adds a new property with the fully qualified name of our class (i.e. org.jackson.dashboards.DatabricksDashboard)

Concrete Types

In case you are deserialising directly into a concrete class and not your interface, then by default Jackson requires you to ensure that the the type information field is available in the JSON payload.

For example, we are aware that Databricks API will only return Databricks dashboard, but the JSON response from API won’t have the type field that we declared for our internal usage.

{
  "id": "databricks-1",
  "content": "hello databricks",
  "deploymentName": "dbc-1234"
}

Jackson being very strict, throws an InvalidTypeIdException in such scenarios. To prevent this error, we have to make this requirement optional in our JsonTypeInfo annotation on the interface.

@JsonTypeInfo(
    use = Id.NAME,
    include = JsonTypeInfo.As.PROPERTY,
    property = "_type",
    requiredIdForSubtypes = OptBoolean.FALSE)

A very curious thing to note is the use of OptBoolean enum here instead of something like true or false; this is because a value type like boolean can’t be null. Also the Java compiler doesn’t allow the use of true or false as these are Java keywords.
