I recently encountered those supposedly theoretical OS concepts from college, in a real production service.

This blog would be like an incident report filled with actual deep technical insights unlike the ones you ought to write for your leadership in the aftermath of an outage.

I would cover the change that caused regression and how it slipped past our QA testing. Then the triage using Claude Code, and coming to a final fix that handles both signal passing and zombie reaping.

Process Signal Handling

In my earlier blog about git crawler uptime, I briefly talked about process signals. Process receive signal from operating system around different events:

  • SIGTERM -> termination signal
  • SIGKILL -> kill program
  • SIGINT -> interrupt program
  • SIGSEGV -> segmentation violation

There is a whole bunch of these through which operating system communicates with processes.

I was working on adding SIGTERM handler into git crawler service on the suspicion of a disk corruption (which wasn’t the case) as a result of not handling SIGTERM properly. For a java servlet (class that handles http requests) it is done by subscribing to context destruction events.

public class GitCrawlerServletContextListener implements ServletContextListener {
  public void contextInitialized(ServletContextEvent servletContextEvent) {
   // dependency injection
  }


  @Override
  public void contextDestroyed(ServletContextEvent servletContextEvent) {
  // ShellCommandRunner executes git commands using thread pool executor
    ShellCommandRunner.shutdownExecutors();
    logger.strictlySafe("Executor Shutdown Successful", Level.INFO);
  }
}

For Git Crawler specifically we perform the following operations on SIGTERM:

  • The thread pool executors are shutdown
  • Running processes receive an InterruptedException
    • Process is sent graceful stop (SIGTERM)
    • Process is forcibly killed (SIGKILL) after a wait of 5s

Signal Passing in Containers

I thought my task was done by implementing signal handling. As you expected it wasn’t otherwise I won’t be writing this blog because:

bash ignores SIGTERM in interactive mode to prevent accidental self termination from commands like kill 0 which are supposed to kill everything in the process group.

This relates to our java service because it is started in a container using a shell script.

ENTRYPOINT ["/home/startup.sh"]

The way around it as our beloved co-worker claude code suggested was to startup java process using exec which makes the java process replace parent process, making it PID1.

java -jar "$JETTY_HOME"/start.jar --exec -XX:MaxRAMPercentage=80.0 -XX:+ExitOnOutOfMemoryError \
exec java -jar "$JETTY_HOME"/start.jar --exec -XX:MaxRAMPercentage=80.0 -XX:+ExitOnOutOfMemoryError \

Now, given the child process itself is PID1 it will receive all the signals from container runtime.

What makes a zombie?

A process carries an entry in process table even after completing so that the parent can check on its exit status. Hence, a parent process has to use system call like wait or waitpid, which reaps the process from process table.

If parent doesn’t reap the child process, child process becomes zombie, and retains entry in process table until restart.

QA Testing

At glean our quality bar is pretty high before shipping things. It enabled our QA team to catch this regression. They raised an escalation but during triage, the errors on-call saw seemed like OOMs. The below was captured in application logs when trying to start a new git command:

java.io.IOException: Cannot run program "bash": error=11, Resource temporarily unavailable

We also saw below error messages in VM system logs:

java.lang.OutOfMemoryError: unable to create native thread: possibly out of memory or process/resource limits reached.

The on-call given the history of OOMs assumed that it was due to memory and started deploy operation to recreate the VM. This led to process table getting purged and QA being able to run their test scenarios without failure this time.

Checking memory metrics after recreation was already underway, it was found that only 12/32Gi was being used. Given QA team was successful at running scenarios and on-call load was too high, nobody spent time on finding the real root cause.

The release went out to all customers but soon enough in the next release’s QA testing this error came up again but this time the on-call spent time on root causing it.

Finding Zombies

On-call took help from claude code and asked it to triage. Claude Code figured out, given access to the virtual machine where service was running that it was due to a large number of zombie processes.

Using below command, we could see that the number of zombie processes was pretty high.

Terminal window
ps -eo pid,ppid,command,args,state | grep -c ^Z

Control Groups have a limit on total number of process ids its allowed to create which could be found as below:

Terminal window
CONTAINER_ID=$(sudo docker inspect klt-git-crawler-ghlv --format '{{.Id}}')
CGROUP_PATH="/sys/fs/cgroup/system.slice/docker-${CONTAINER_ID}.scope"


cat ${CGROUP_PATH}/pids.current   # → 38515
cat ${CGROUP_PATH}/pids.max       # → 38515
cat ${CGROUP_PATH}/cgroup.procs | wc -l   # → 2

From the results, we understood that there were a lot of “orphaned processes” which were becoming zombies as java wasn’t reaping them, unlike bash.

A quick workaround is by setting the PID limit to max which allows more processes to be created.

Terminal window
echo max > ${CGROUP_PATH}/pids.max

Signal & Reaping

Given SIGTERM handling was less important than preventing zombie process accumulation we reverted the change and cherry-picked to all the customers.

The next step was to use a better init process for our containers that:

  • Handles SIGTERM by propagating to the children
  • Reaps zombie processes

The alternatives that are readily used are tini and dumb-init.

We also went ahead with using tini as the init process and java process started using exec replacing its parent shell.

  • tini reaps zombies as PID1
  • java receives SIGTERM

Final Thoughts

Nobody, ever said how much fun they had as on-call, but here I must even though I wasn’t on-call. Being involved in triage and seeing the theoretical concepts taught in class come to life was pretty educating.

Even though I was aware of tini, I never understood its requirement maybe I shouldn’t have been lazy and read its why tini? section. I hope you are aware of the repercussions of not using the right init process for containers now.

I’m still trying to figure out what particularly in our usage of git command execution caused zombie spawn. A hint was it had something to do with pattern of using sub-shells while running commands. Each sub-shell spawns a new process which doesn’t get reaped.

Terminal window
bash -c "
  (cd $REPO_DIR && git remote set-url origin $FETCH_URL) &&
  (if git rev-parse --verify HEAD --quiet >/dev/null 2>&1; then
    git log --oneline $LAST_KNOWN_HEAD;
  fi) &&
  (echo DONE > $METADATA_ID.status)
"
plants vs zombies

Nevertheless, I hope everyone keeps those zombies in check! Thanks for reading, see you in the next blog.
